THE AIRCRAFT COLLECTION · Educational

Six airplanes, each with a way in.

Everything on this site that lets you take an airplane apart, investigate it, decide for it or move its shock waves, in one place. An aircraft shown here as interactive has a working interaction; an aircraft without one sits in the backlog and says so. Every technical claim carries its source, and every completion is recorded in My Hangar on this device.

Browse the collection The Hangar on the homepage
Exploded view of the Learjet 24 training model from the Aircraft Atlas: nose, cabin shell, wings, tip tanks, engine nacelles and T-tail spread apart
An illustrative training model rendered from the Aircraft Atlas, not a photograph. Lloyd's Lear 24XR is the collection's flagship; the model shows nothing about the airplane's present condition or equipment.

01 / THE COLLECTION

FIVE INTERACTIVE · ONE IN THE BACKLOG

The aircraft

Exploded view of the Learjet 24 training model from the Aircraft Atlas

Learjet · Lloyd's airplane · N24SA

Lloyd's Lear 24XR

The flagship: an original exploded view built from public drawings, the verified story of serial 24-117, and a separate chapter on the NASA Learjet that carried a telescope.

Illustrative training model rendered from the Atlas, not a photograph of the airplane.

An SR-71B Blackbird trainer in flight over snow-covered mountains

Lockheed · Mach 3 reconnaissance

SR-71 Blackbird

At Mach 3 the inlets made most of the thrust, and where their shock waves stood decided everything. An illustrative inlet you can unstart, a sourced dossier and a five-question challenge.

Reference photograph: SR-71B trainer, NASA 831, over the Sierra Nevada in 1994. USAF / Judson Brohmer, public domain.

original schematic, not to scale

Concorde · supersonic airliner

Concorde

A wing that flies at Mach 2 does not lift from the same place it lifts from at 300 knots. How the crew moved about 20 tonnes of fuel to follow it, with the sources that say so.

No photograph: the images on the Airbus source page are © Airbus. The drawing is an original schematic.

IN THE BACKLOG no exhibit, no link, until the content is verified

Lockheed · high-altitude research · later

U-2 / NASA ER-2

High-altitude research and atmospheric measurement, with the actual variants and their data kept distinct. NASA operates two ER-2s as flying laboratories from Armstrong's Building 703 in Palmdale, at 20,000 to 70,000 ft, "above 99 percent of the Earth's atmosphere" (NASA, ER-2 aircraft page, updated September 29, 2023). It joins the collection when it has enough verified content; until then there is nothing here to click, on purpose.

Documented backlog entry. No photograph is used; NASA's ER-2 imagery (credit NASA/Carla Thomas) would be reusable with credit when the exhibit exists.

02 / ON THIS DEVICE

MY HANGAR · STORED IN THIS BROWSER ONLY

What you have finished here.

Each experience above ends with a completion state that is recorded in My Hangar on this device: a study record, never a rating, endorsement or qualification. Nothing syncs between devices or between lloydpilot.com and play.lloydpilot.com.

  • Nothing recorded on this device yet. The links above mark themselves when you finish.

Open My Hangar to see, export or delete everything stored here.

03 / HOW THE COLLECTION WORKS

THE RULES EVERY PAGE FOLLOWS

Depth over catalogue.

  • Interactive means working. A control on these pages does something end to end, or it is not there. Unfinished aircraft stay in the backlog with no link.
  • Every claim has a locator. Document, edition, page or section, and a link, in a sources drawer near the content, with a "suggest a correction" line.
  • Models say what they are. The SR-71 inlet and the Concorde diagram are illustrative, with their assumptions written down; the Systems Detective case and the Captain’s Call scenario are synthetic and frozen; the Lear model is original geometry from public drawings.
  • Identities stay separate. Lloyd's Lear 24XR is N24SA, serial 24-117; NASA's Learjet observatory is a different airplane; the Cherokee and Baron photographs are type photographs, not Lloyd's aircraft.
  • Records stay yours. Completions, answers and notes live in this browser, visible in My Hangar, exportable and deletable there.

Photography and sources for the whole site: Photography & sources. Each experience carries its own drawer as well.

ABOUT THE COLLECTION

Educational. Aircraft are added when they have enough verified content for a working experience, not before. Suggestions and corrections are welcome through the sources line on any page.
